Drillholes Summary
On the Drillholes Summary tab of the Plot Options form, choose which drillhole summary totals to include in (or excluded from) the plot.
The Drillholes Summary is a table which summarises the main properties of the round, including the heading surface area, total number of drillholes, total drillhole meters, holes by hole type and total Mass of Explosives used in the round.
Use the check box options (or click Select All) to include summary information in the plot. The Summary Table grid control allows the number and the order of the database fields included in the summary to be easily adjusted. You can use the buttons on the toolbar (or use the right-click menu) to manipulate the order of the rows in the list.
You can use the Expression button for each field to build an expression.
|
Click to Move selected rows Up or Down. |
|
Click Autofill to reset the list of fields and their default values. |
To edit the Display Name for a field, double-click on the cell to make it editable.
